获取用户创建的填表模板列表

调用本接口,获取用户创建的填表模板列表。

例如,依次单击工作台 > 智能填表 > 统计 > 我创建的,查看到当前用户创建了测试周期填表测试一次性填表2个填表模板。如下图所示。

调用本接口可以获取这2个模板的信息,包括填表名称、填表提示、填表类型等。

说明

目前智能填表目前仅支持查询旧版界面创建的表单数据,新版界面创建的表单无法查询。


权限

要调用此API,需要以下权限之一。

应用类型

是否支持

权限

API Explorer调试

企业内部应用

支持

智能填表数据读取权限

API Explorer

第三方企业应用

支持

智能填表数据读取权限

API Explorer

第三方个人应用

暂不支持

智能填表数据读取权限

暂不支持

请求方法

GET /v1.0/swform/users/forms?maxResults=Integer&bizType=Integer&creator=String&nextToken=Long HTTP/1.1
Host:api.dingtalk.com
x-acs-dingtalk-access-token:String
Content-Type:application/json

Header参数

名称

类型

是否必填

描述

x-acs-dingtalk-access-token

String

调用该接口的访问凭证。

Query参数

名称

类型

是否必填

描述

maxResults

Integer

每页最大条目数,最大值200。

bizType

Integer

填表类型。

  • 0:表示通用填表

  • 1:表示教育版填表

creator

String

填表创建人userid。

nextToken

Long

分页游标。

  • 如果是首次查询,该参数传0。

  • 如果是非首次查询,该参数传上次调用时返回的nextToken值。

返回参数

名称

类型

描述

success

Boolean

接口调用是否成功。

  • true:成功

  • false:失败

result

Object

返回结果。

hasMore

Boolean

是否有下一页数据。

  • true:是

  • false:否

nextToken

Long

分页游标。

list

Array

创建的表单模板列表。

creator

String

创建人userId。

formCode

String

填表code。

name

String

填表名称。

memo

String

填表提示。

setting

Object

表单设置信息。

bizType

Integer

填表类型。

  • 0:通用填表

  • 1:教育版填表

createTime

String

创建时间,iso8601格式,例如:2022-07-29T14:55Z。

formType

Integer

表单类型。

  • 0:一次性填表

  • 1:周期性填表

stop

Boolean

填表是否已终止。

  • true:已经终止

  • false:未终止

loopTime

String

周期性填表的提醒时间点。

说明

一次性填表类型,不返回该字段。

loopDays

Array of Integer

填表周期,周一到周日分别用1-7表示。

endTime

String

填表截止时间,iso8601格式,例如:2022-07-29T14:55Z。

示例

请求示例

GET /v1.0/swform/users/forms?maxResults=10&bizType=0&creator=manager4220&nextToken=0 HTTP/1.1
Host:api.dingtalk.com
x-acs-dingtalk-access-token:Be3xxxx
Content-Type:application/json
// This file is auto-generated, don't edit it. Thanks.
package com.aliyun.sample;

import com.aliyun.tea.*;
import com.aliyun.teautil.*;
import com.aliyun.teautil.models.*;
import com.aliyun.dingtalkswform_1_0.*;
import com.aliyun.dingtalkswform_1_0.models.*;
import com.aliyun.teaopenapi.*;
import com.aliyun.teaopenapi.models.*;

public class Sample {

    /**
     * 使用 Token 初始化账号Client
     * @return Client
     * @throws Exception
     */
    public static com.aliyun.dingtalkswform_1_0.Client createClient() throws Exception {
        Config config = new Config();
        config.protocol = "https";
        config.regionId = "central";
        return new com.aliyun.dingtalkswform_1_0.Client(config);
    }

    public static void main(String[] args_) throws Exception {
        java.util.List<String> args = java.util.Arrays.asList(args_);
        com.aliyun.dingtalkswform_1_0.Client client = Sample.createClient();
        ListFormSchemasByCreatorHeaders listFormSchemasByCreatorHeaders = new ListFormSchemasByCreatorHeaders();
        listFormSchemasByCreatorHeaders.xAcsDingtalkAccessToken = "<your access token>";
        ListFormSchemasByCreatorRequest listFormSchemasByCreatorRequest = new ListFormSchemasByCreatorRequest()
                .setMaxResults(10)
                .setBizType(0)
                .setCreator("manager4220")
                .setNextToken(0L);
        try {
            client.listFormSchemasByCreatorWithOptions(listFormSchemasByCreatorRequest, listFormSchemasByCreatorHeaders, new RuntimeOptions());
        } catch (TeaException err) {
            if (!com.aliyun.teautil.Common.empty(err.code) && !com.aliyun.teautil.Common.empty(err.message)) {
                // err 中含有 code 和 message 属性,可帮助开发定位问题
            }

        } catch (Exception _err) {
            TeaException err = new TeaException(_err.getMessage(), _err);
            if (!com.aliyun.teautil.Common.empty(err.code) && !com.aliyun.teautil.Common.empty(err.message)) {
                // err 中含有 code 和 message 属性,可帮助开发定位问题
            }

        }
    }
}
# -*- coding: utf-8 -*-
# This file is auto-generated, don't edit it. Thanks.
import sys

from typing import List

from alibabacloud_dingtalk.swform_1_0.client import Client as dingtalkswform_1_0Client
from alibabacloud_tea_openapi import models as open_api_models
from alibabacloud_dingtalk.swform_1_0 import models as dingtalkswform__1__0_models
from alibabacloud_tea_util import models as util_models
from alibabacloud_tea_util.client import Client as UtilClient


class Sample:
    def __init__(self):
        pass

    @staticmethod
    def create_client() -> dingtalkswform_1_0Client:
        """
        使用 Token 初始化账号Client
        @return: Client
        @throws Exception
        """
        config = open_api_models.Config()
        config.protocol = 'https'
        config.region_id = 'central'
        return dingtalkswform_1_0Client(config)

    @staticmethod
    def main(
        args: List[str],
    ) -> None:
        client = Sample.create_client()
        list_form_schemas_by_creator_headers = dingtalkswform__1__0_models.ListFormSchemasByCreatorHeaders()
        list_form_schemas_by_creator_headers.x_acs_dingtalk_access_token = '<your access token>'
        list_form_schemas_by_creator_request = dingtalkswform__1__0_models.ListFormSchemasByCreatorRequest(
            max_results=10,
            biz_type=0,
            creator='manager4220',
            next_token=0
        )
        try:
            client.list_form_schemas_by_creator_with_options(list_form_schemas_by_creator_request, list_form_schemas_by_creator_headers, util_models.RuntimeOptions())
        except Exception as err:
            if not UtilClient.empty(err.code) and not UtilClient.empty(err.message):
                # err 中含有 code 和 message 属性,可帮助开发定位问题
                pass

    @staticmethod
    async def main_async(
        args: List[str],
    ) -> None:
        client = Sample.create_client()
        list_form_schemas_by_creator_headers = dingtalkswform__1__0_models.ListFormSchemasByCreatorHeaders()
        list_form_schemas_by_creator_headers.x_acs_dingtalk_access_token = '<your access token>'
        list_form_schemas_by_creator_request = dingtalkswform__1__0_models.ListFormSchemasByCreatorRequest(
            max_results=10,
            biz_type=0,
            creator='manager4220',
            next_token=0
        )
        try:
            await client.list_form_schemas_by_creator_with_options_async(list_form_schemas_by_creator_request, list_form_schemas_by_creator_headers, util_models.RuntimeOptions())
        except Exception as err:
            if not UtilClient.empty(err.code) and not UtilClient.empty(err.message):
                # err 中含有 code 和 message 属性,可帮助开发定位问题
                pass


if __name__ == '__main__':
    Sample.main(sys.argv[1:])
<?php

// This file is auto-generated, don't edit it. Thanks.
namespace AlibabaCloud\SDK\Sample;

use AlibabaCloud\SDK\Dingtalk\Vswform_1_0\Dingtalk;
use \Exception;
use AlibabaCloud\Tea\Exception\TeaError;
use AlibabaCloud\Tea\Utils\Utils;

use Darabonba\OpenApi\Models\Config;
use AlibabaCloud\SDK\Dingtalk\Vswform_1_0\Models\ListFormSchemasByCreatorHeaders;
use AlibabaCloud\SDK\Dingtalk\Vswform_1_0\Models\ListFormSchemasByCreatorRequest;
use AlibabaCloud\Tea\Utils\Utils\RuntimeOptions;

class Sample {

    /**
     * 使用 Token 初始化账号Client
     * @return Dingtalk Client
     */
    public static function createClient(){
        $config = new Config([]);
        $config->protocol = "https";
        $config->regionId = "central";
        return new Dingtalk($config);
    }

    /**
     * @param string[] $args
     * @return void
     */
    public static function main($args){
        $client = self::createClient();
        $listFormSchemasByCreatorHeaders = new ListFormSchemasByCreatorHeaders([]);
        $listFormSchemasByCreatorHeaders->xAcsDingtalkAccessToken = "<your access token>";
        $listFormSchemasByCreatorRequest = new ListFormSchemasByCreatorRequest([
            "maxResults" => 10,
            "bizType" => 0,
            "creator" => "manager4220",
            "nextToken" => 0
        ]);
        try {
            $client->listFormSchemasByCreatorWithOptions($listFormSchemasByCreatorRequest, $listFormSchemasByCreatorHeaders, new RuntimeOptions([]));
        }
        catch (Exception $err) {
            if (!($err instanceof TeaError)) {
                $err = new TeaError([], $err->getMessage(), $err->getCode(), $err);
            }
            if (!Utils::empty_($err->code) && !Utils::empty_($err->message)) {
                // err 中含有 code 和 message 属性,可帮助开发定位问题
            }
        }
    }
}
$path = __DIR__ . \DIRECTORY_SEPARATOR . '..' . \DIRECTORY_SEPARATOR . 'vendor' . \DIRECTORY_SEPARATOR . 'autoload.php';
if (file_exists($path)) {
    require_once $path;
}
Sample::main(array_slice($argv, 1));
// This file is auto-generated, don't edit it. Thanks.
package main

import (
  "os"
  util  "github.com/alibabacloud-go/tea-utils/service"
  dingtalkswform_1_0  "github.com/alibabacloud-go/dingtalk/swform_1_0"
  openapi  "github.com/alibabacloud-go/darabonba-openapi/client"
  "github.com/alibabacloud-go/tea/tea"
)


/**
 * 使用 Token 初始化账号Client
 * @return Client
 * @throws Exception
 */
func CreateClient () (_result *dingtalkswform_1_0.Client, _err error) {
  config := &openapi.Config{}
  config.Protocol = tea.String("https")
  config.RegionId = tea.String("central")
  _result = &dingtalkswform_1_0.Client{}
  _result, _err = dingtalkswform_1_0.NewClient(config)
  return _result, _err
}

func _main (args []*string) (_err error) {
  client, _err := CreateClient()
  if _err != nil {
    return _err
  }

  listFormSchemasByCreatorHeaders := &dingtalkswform_1_0.ListFormSchemasByCreatorHeaders{}
  listFormSchemasByCreatorHeaders.XAcsDingtalkAccessToken = tea.String("<your access token>")
  listFormSchemasByCreatorRequest := &dingtalkswform_1_0.ListFormSchemasByCreatorRequest{
    MaxResults: tea.Int32(10),
    BizType: tea.Int32(0),
    Creator: tea.String("manager4220"),
    NextToken: tea.Int64(0),
  }
  tryErr := func()(_e error) {
    defer func() {
      if r := tea.Recover(recover()); r != nil {
        _e = r
      }
    }()
    _, _err = client.ListFormSchemasByCreatorWithOptions(listFormSchemasByCreatorRequest, listFormSchemasByCreatorHeaders, &util.RuntimeOptions{})
    if _err != nil {
      return _err
    }

    return nil
  }()

  if tryErr != nil {
    var err = &tea.SDKError{}
    if _t, ok := tryErr.(*tea.SDKError); ok {
      err = _t
    } else {
      err.Message = tea.String(tryErr.Error())
    }
    if !tea.BoolValue(util.Empty(err.Code)) && !tea.BoolValue(util.Empty(err.Message)) {
      // err 中含有 code 和 message 属性,可帮助开发定位问题
    }

  }
  return _err
}


func main() {
  err := _main(tea.StringSlice(os.Args[1:]))
  if err != nil {
    panic(err)
  }
}
// This file is auto-generated, don't edit it
import Util, * as $Util from '@alicloud/tea-util';
import dingtalkswform_1_0, * as $dingtalkswform_1_0 from '@alicloud/dingtalk/swform_1_0';
import OpenApi, * as $OpenApi from '@alicloud/openapi-client';
import * as $tea from '@alicloud/tea-typescript';


export default class Client {

  /**
   * 使用 Token 初始化账号Client
   * @return Client
   * @throws Exception
   */
  static createClient(): dingtalkswform_1_0 {
    let config = new $OpenApi.Config({ });
    config.protocol = "https";
    config.regionId = "central";
    return new dingtalkswform_1_0(config);
  }

  static async main(args: string[]): Promise<void> {
    let client = Client.createClient();
    let listFormSchemasByCreatorHeaders = new $dingtalkswform_1_0.ListFormSchemasByCreatorHeaders({ });
    listFormSchemasByCreatorHeaders.xAcsDingtalkAccessToken = "<your access token>";
    let listFormSchemasByCreatorRequest = new $dingtalkswform_1_0.ListFormSchemasByCreatorRequest({
      maxResults: 10,
      bizType: 0,
      creator: "manager4220",
      nextToken: 0,
    });
    try {
      await client.listFormSchemasByCreatorWithOptions(listFormSchemasByCreatorRequest, listFormSchemasByCreatorHeaders, new $Util.RuntimeOptions({ }));
    } catch (err) {
      if (!Util.empty(err.code) && !Util.empty(err.message)) {
        // err 中含有 code 和 message 属性,可帮助开发定位问题
      }

    }
  }

}

Client.main(process.argv.slice(2));
// This file is auto-generated, don't edit it. Thanks.

using System;
using System.Collections;
using System.Collections.Generic;
using System.IO;
using System.Threading.Tasks;

using Tea;
using Tea.Utils;


namespace AlibabaCloud.SDK.Sample
{
    public class Sample
    {

        /**
         * 使用 Token 初始化账号Client
         * @return Client
         * @throws Exception
         */
        public static AlibabaCloud.SDK.Dingtalkswform_1_0.Client CreateClient()
        {
            AlibabaCloud.OpenApiClient.Models.Config config = new AlibabaCloud.OpenApiClient.Models.Config();
            config.Protocol = "https";
            config.RegionId = "central";
            return new AlibabaCloud.SDK.Dingtalkswform_1_0.Client(config);
        }

        public static void Main(string[] args)
        {
            AlibabaCloud.SDK.Dingtalkswform_1_0.Client client = CreateClient();
            AlibabaCloud.SDK.Dingtalkswform_1_0.Models.ListFormSchemasByCreatorHeaders listFormSchemasByCreatorHeaders = new AlibabaCloud.SDK.Dingtalkswform_1_0.Models.ListFormSchemasByCreatorHeaders();
            listFormSchemasByCreatorHeaders.XAcsDingtalkAccessToken = "<your access token>";
            AlibabaCloud.SDK.Dingtalkswform_1_0.Models.ListFormSchemasByCreatorRequest listFormSchemasByCreatorRequest = new AlibabaCloud.SDK.Dingtalkswform_1_0.Models.ListFormSchemasByCreatorRequest
            {
                MaxResults = 10,
                BizType = 0,
                Creator = "manager4220",
                NextToken = 0,
            };
            try
            {
                client.ListFormSchemasByCreatorWithOptions(listFormSchemasByCreatorRequest, listFormSchemasByCreatorHeaders, new AlibabaCloud.TeaUtil.Models.RuntimeOptions());
            }
            catch (TeaException err)
            {
                if (!AlibabaCloud.TeaUtil.Common.Empty(err.Code) && !AlibabaCloud.TeaUtil.Common.Empty(err.Message))
                {
                    // err 中含有 code 和 message 属性,可帮助开发定位问题
                }
            }
            catch (Exception _err)
            {
                TeaException err = new TeaException(new Dictionary<string, object>
                {
                    { "message", _err.Message }
                });
                if (!AlibabaCloud.TeaUtil.Common.Empty(err.Code) && !AlibabaCloud.TeaUtil.Common.Empty(err.Message))
                {
                    // err 中含有 code 和 message 属性,可帮助开发定位问题
                }
            }
        }


    }
}

返回示例

HTTP/1.1 200 OK
Content-Type:application/json

{
  "success" : true,
  "result" : {
    "hasMore" : true,
    "nextToken" : 10,
    "list" : [ {
      "creator" : "manager4220",
      "formCode" : "PROC-E5BD2166-B6F4-xxxx",
      "name" : "智能填表测试",
      "memo" : "请大家仔细填写,谢谢合作",
      "setting" : {
        "bizType" : 0,
        "createTime" : "2022-07-27T18:53Z",
        "formType" : 0,
        "stop" : true,
        "loopTime" : "18:00",
        "loopDays" : [ 1 ],
        "endTime" : "2022-07-27T18:53Z"
      }
    } ]
  }
}

错误码

HttpCode

错误码

错误信息

说明

400

swform.listFormSchemasByCreator.paramError

invalid biz_type

填表类型参数非法,当前仅支持0:通用智能填表 1:教育版填表

400

swform.listFormSchemasByCreator.paramError

param invalid

获取用户创建的填表模板列表参数异常

400

swform.listFormSchemasByCreator.paramError

invalid offset

nextToken请求参数不合法

400

swform.listFormSchemasByCreator.paramError

invalid size

maxResults请求参数不合法,最大支持200

400

swform.listFormSchemasByCreator.paramError

app not exist

应用不存在

400

swform.listFormSchemasByCreator.paramError

app has been stoped

应用已停用

400

swform.listFormSchemasByCreator.paramError

getFormListByCreator fail

获取用户创建的表单模板列表失败

500

swform.listFormSchemasByCreator.sysError

swform.listFormInstances.sysError

获取用户创建的填表模板列表系统异常
